CP Plus 6 Port Fast Ethernet Switch with 4 PoE

CP Plus Switch

The CP Plus 6 Port Fast Ethernet PoE Switch (CP-DNW-GPU4G2-48) is a high, lean and kind network solution that is suitable for small to medium sized business, security areas and home networks. This switch has 4 Gb PoE ports (1000 Mbps) and 2 Gb uplink ports (1000 Mbps), providing high-throughput of data transfer between multiple devices with a smooth connection.

Providing 4 Power over Ethernet (PoE) ports, this switch is rated for a maximum PoE port output of 30W and includes a total PoE power budget of 48W. It automatically detects and powers connected PoE-enabled devices such as IP cameras, VoIP phones, and wireless access points, eliminating the need for separate power sources and reducing cable clutter.

The 2 Gbps uplink ports support high-speed and stable communication with routers, NVRs, or other network element to guarantee a lag-free data flow to any demanding applications. The switch adheres to IEEE802.3i/802.3u/802.3x/802.3ab standards so it is compatible to most kinds of network equipments.

The CP Plus PoE switch is a plug-and-play. Because it's plug-and-play, users can connect devices without complicated configurations. It is suitable not only to the beginner, but also the IT professional, who requires an easy-to-handle networking solution efficient.

With a transmission range of up to 100 meters, this switch is ideal for extending office, storefront, surveillance, and smart home networks. The intelligent power management feature protects connected devices from overloading, overheating, and short circuits, ensuring stable and reliable performance.

The switch has LEDs that provide real-time status indication (power, link and PoE activity). These markers are used to instantly recognize network problems and provide an uninterrupted and smooth operation.

Buy the CP Plus 6 Port Fast Ethernet PoE Switch (CP-DNW-GPU4G2-48) for lowest price from RadiumBox. Enjoy free shipping, COD options, and reliable customer support. For inquiries, call +91-8434384343 or email [email protected]. Upgrade your network with CP Plus - the powerhouse PoE switch that delivers the speed and simplicity of it all!

Specification

• Product

• Brand: CP Plus

• Model: CP Plus 6

• Type: Switch

• Manufacturer: ‎CP PLUS

• Country of Origin: ‎India

• General Specifications

• Switch Capacity: 12 Gbps (Full Duplex)

• Network Ports: 6

• Uplink Ports: 2 × 1000 Mbps (Transmission Distance: 0-100m)

• PoE Ports: 4 × 1000 Mbps (RJ45)

• PoE Power Budget: 48W

• PoE Standard: IEEE 802.3af, IEEE 802.3at

• PoE Power Supply: 1/2 (+), 3/6 (-)

• Maximum Output per PoE Port: 30W

• Transmission Distance: 0-100m

• Performance & Security

• Packet Forwarding Rate: 1.488 Mpps per port

• MAC Address List: 2K

• Anti-Thunder Level:

• Common Mode: 2KV

• Differential Mode: 2KV

• ESD Protection

• Air Discharge: 1.5KV

• Contact Discharge: 1.5KV

• Ethernet Port Light Indicators

• Light Off: Link is disconnected

• Red Light On: Powering but data disconnected

• Fast Flashing Light: Data transmitting

• Power & Environmental

• Power Source: Built-in Power Supply (Input: 110-264V AC, 50/60Hz)

• Power Consumption: <5W

• Operating Temperature: -10°C to -50°C

• Humidity: 10%-95% (Non-Condensing)

• Storage Temperature: -40°C to 70°C

• Weight & Dimensions

• Size (L×W×H): 202mm × 140mm × 45mm

• Weight: ‎600 g

Key Features

• 6-Port Gigabit Ethernet Switch – 4 PoE ports (1000 Mbps) + 2 Gigabit uplink ports (1000 Mbps).

• Max. 30W Output per PoE Port – Supports PoE-enabled devices like IP cameras, VoIP phones, and access points.

• PoE Power Budget: 48W – Efficient power management for multiple devices.

• Supports IEEE802.3i/802.3u/802.3x/802.3ab – Ensures compatibility with various network devices.

• Transmission Distance: 0-100m – Suitable for security setups, offices, and commercial networks.

• Plug & Play Installation – No software configuration required.

• LED Indicators – Provides real-time status monitoring for easy troubleshooting.

• Surveillance Systems – Connect and power IP cameras effortlessly.

• VoIP Communications – Reliable connectivity for VoIP phones.

• Wireless Networks  Power and connect APs without the need for adapters.

• Small Office/Home Networks – Enhance network stability and performance.

Note: It is recommended to verify all the characteristics and costs before making any purchase.
