Description
Bluetooth Support
- Bluetooth-enabled mobile key solution
- Terminal Menu Control in Mobile Phone (iAccess M Plus)
- Mobile Card Authentication (NITGEN Mobile Card)
IP65 Rated Weatherproof
- Water and Dust Resistance
Fake Finger Detection
- Optical sensor and algorithm detect fake fingers
(Paper, Film, Silicone, Rubber and Gelatin)
Terminal Status Indicator
- 3 Color LED Indicator
- Beep & Voice Sound Indicator
Built-in Camera
- Storage and Monitoring of Image Logs
Authentication Method | Biometric | ||
Dust/ Water Resistance | IP65 | ||
Memory | Max User | 10,000 | |
Fingerprints (Templates) | 10,000 (1:1)(1:N) | ||
Logs | 100,000 | ||
Images | 10,000 | ||
Communi-cation | With Server | TCP/IP | |
Other | Bluetooth/USB | ||
Wireless LAN(Wi-Fi) | X | ||
Wiegand OUT | O | ||
RS232 | X | ||
RS485 | OSDP | ||
Wiegand IN | O | ||
Display | LCD | 1.77"Color LCD | |
Backlight | O | ||
Embedded Camera | O | ||
Card | 125khz-EM | O | |
HID Prox | O | ||
HID iclass | X | ||
13.56MHz Smart Card | O | ||
Keypad | X | ||
Function keys | 4 | ||
Door Phone | X | ||
FP Sensor | Platen Area | 14.8 X 17.9mm | |
Resolution | 500 dpi | ||
Authentication Speed | (1:1) | < 0.5 sec | |
1:N(1,000) | < 1 sec | ||
Dimension | (W) X (H) X (D) mm | 58 X 187.9 X 51.6 | |
FRR /FAR | 0.1% /0.0001% | ||
Operating Temperature | -20 ~ 60℃ | ||
Opertating Software(S/W Solution) | AccessManager Pro |
