eNBioAccess-T5 S (POE Included)

eNBioAccess-T5 (POE)

The device eNBioAccess T5 S is a bioptic access and time attendance controller that incorporates only the highest of quality features for usage in today’s security environment. Using TCP/IP communication technology, this device can provide comprehensive connectivity and high PoE power design, thus becoming an important application solution for corporate, industrial, and educational areas.

This is the modern device that incorporates biometric design for authentication such as fingerprint scan in addition to RFID cards and PIN. These technologies are integrated to offer a more secure security mechanism that can be used by different users depending on their requirement. That is why the eNBioAccess T5 S has a matching engine that is significantly better than its competitors and was awarded the first place in the Fingerprint Verify Competition (FVC).

The 2.4-inch TFT color LCD display is easy to use with a notice/status bar where one can input their commands. There is also other top level functions throughout the device marked from F1 to F4 that can be applied by a touch keypad for customized functions to suit certain needs. To support the offline treatment for the mass data copy, the eNBioAccess T5 S comes with the USB memory slot, allowing the treatment with USB memory stick.

Apart from the biometric systems, the eNBioAccess T5 S includes a built-in camera to take pictures of the transaction process and store them on the server. This feature helps to increase responsibility and will contain a report of the access events. The eNBioAccess T5 S is a durable GSM mobile that is suitable to use in testy environments. It is designed in an IP54 sealed housing that makes the device dustproof and waterproof to withstand challenging environments.

They are not only a performer but also flexibility around the eNBioAccess T5 S, and the eNBioAccess T5 S. It can complement traditional means of security like deadbolts, electromagnetic lock, door strikes and automatic doors. Besides that, it offers industry-oriented time attendance management to facilitate clock-in/clock-out tracking and missed time tracking.

Being packed with the latest technology and installed with friendly user interface this eNBioAccess T5 S is an ideal solution for enterprise level access control and time attendance management. Regardless if an office setting for companies or in school facilities, this device addresses security requirements of present times flexible enough not to compromise convenience and dependability. To know more details or to buy the eNBioAccess T5 S at reasonable prices you can visit Radium Box or call at +91-8434384343 or email at [email protected].

Specifications

• Product

• Brand: Bioenable

• Name: eNBioAccess T5 S (POE Included)

• Model: MF; EM; HID; Standard

• Warranty: 1 Year

• Key Specifications

• CPU: S3C6410 (ARM11) 667 MHz

• Memory: 256 MB DRAM / 256 MB Flash

• Display: 4.3” TFT LCD / Touch Screen

• Sensor: Optical / 500 DPI

• Authentication Types: Fingerprint, Password, RF Card

• Communication Interfaces: TCP/IP; Wiegand In/Out (26/34 bit)

• Supported Locks:

• Deadbolt

• EM Lock

• Door Strike

• Automatic Door

• Performance Metrics

• 1:1 Authentication Time: < 0.2 seconds

• 1:N Authentication Time: < 1 second (up to 4,000 templates)

• Capacity

• Template Capacity: 100,000 templates (2 templates per finger, up to 50,000 users)

• Log Capacity: 500,000 logs

• Environmental Specifications

• Operating Temperature Range: -20°C to +60°C

• Operating Humidity: < RH 90%

• Certifications

• Certifications: KC, CE, FCC

• Physical Specifications

• Dimensions (W x H x D): 192 mm x 156 mm x 55 mm

• System Configuration

• S/W Package: AccessManager Pro

• Max Accessing Terminals: Up to 2,000 EA

• Max Remote Clients: Up to 16 (Access Manager)

• Operating System Compatibility: Windows XP or higher

• Max Users Supported on Server: Up to 100,000 users

Key Features

• Voice Status Messages: Gives audio feedback while interacting with the user.

• 4.3-inch Color LCD with Touch Screen:It has an easy to handle interface that enables most users to easily interact with it or navigate through it.

• Fingerprint Image Quality Check:Prevents low qualified fingerprint scans from ever being used for authentication purposes.

• Notice / Status Bar:Shows notification and status of the system that are important to the user.

• Customizable Wallpaper:Enables displaying of the company logo so as to promote the image of the company.

• Superior Matching Engine:First on the list of FVC as established on its precision and the reliability of the techniques used.

• Auto-On Function & Live Finger Detection:Powerful and intuitive, this turns on the device as soon as one of the fingers is placed on the sensor pad.

• Built-in Camera:Clicks picture for each transaction that is taken and saves the pictures on the server to avoid threats.

• USB Memory Slot:It supports the transfer of data on a USB memory stick in particular with relative ease.

• Function Keys:Four of them are user-defined functions which include F1 clock in, F2 clock out, F3 absence, F4 return.

• Multifactor Authentication:Supports the fingerprint, RF card, and password for increased security of the system.

• Multi-Language Support with Audio-Visual Indications:Makes access to the finishing resources easier for users of different language with visual and/or audio cues.

• Built-in battery & PoE (Power over Ethernet) support: ensures continuous operation during power failures and easy installation through PoE technology.

• Centralized Biometric Access Control on IP Technology Enables the integrated monitoring and management of multiple terminals scattered across different locations.

Note: Before using the device, please check the app specifications to ensure compatibility.
