Futronic FS 88 H Single Fingerprint USB Biometric Scanner

Futronic FS 88 H Single Fingerprint USB Biometric Scanner

The FS88H Single Futronic Fingerprint USB Biometric Scanner is a high-performance, high-quality, and security-oriented optical fingerprint scanner. It is certified by the FBI and fully complies with the PIV-071006 Image Quality Specification, thus complying with the US Federal Information.

Processing Standard 201 (FIPS 201) for Personal Identification Verification: This certification makes FS88H ideal for applications ranging from border control, issuance of identity cards, driver licenses, and elections to civilian AFIS.

The advanced CMOS sensor technology used in the FS88H allows it to capture distortion-free fingerprint images at a resolution of 500 DPI with a matrix of 320 x 480 pixels. This scanner is robust in its design; it is made of 14mm crown glass as the scanning window. Hence, it can withstand scratches and provide long-term durability. The product uses infrared LEDs to illuminate the finger when it is being scanned. The intensity of the light depends on the state of the fingerprint, if it's wet, dry, or blurred. This adaptive illumination significantly improves the quality of the captured image. But FS88H contains an even more striking feature—the possibility of live finger detection, meaning that fake fingers made from materials like silicone or plasticine cannot be used. This feature can easily be turned on or off using compatible software on your PC, thus providing impressive versatility for a plethora of security needs. The scanner rejects non-live fingers to ensure the capture of real biometric data only.

It is not only strong, but the FS88H is also user-friendly. It connects via USB 2.0, making it plug-and-play and easy to set up or integrate with other systems that may exist.

The Futronic FS88 fingerprint scanner driver download is at one's disposal, just like the Futronic fingerprint scanner software download, to smoothen the operations in case they need a boost. It also provides the facility to download the driver of the Futronic FS80H Fingerprint Scanner for Windows 10 so as to be compatible with modern OS.

Aside from its feature, FS88H makes use of a unique serial number factory-programmed in the USB Device Descriptor for traceability, which is an important requirement with respect to identity management projects in the government sector. Weighing only 150 grams with compact dimensions of 66 x 66 x 29 mm, this scanner comes lightweight and easy to carry.

The SDK of the Futronic fingerprint scanner provides all necessary tools for developing custom applications using this device.

Be it implementing biometric authentication in secure environments or simply automating identity verification, Futronic FS88H - Stocks News offers a reliable and efficient solution.

Buy The Futronic FS88H Single Fingerprint USB Biometric Scanner at the best price available in India from Radium Box, as we sell at an effective price so that every amount you pay will have great value for money. We also provide you with the required driver downloads to ensure smooth integration and secure operation. In case of any installation assistance, driver downloads, or any other inquiry, you can reach our customer care at +91 84343 84343 or can mail us at [email protected]. Our responsive team is here to help you with any queries and hassle-free experience for your device in the biometric solution. Keep updated about the latest software and driver upgrades available for your device.

Specification

• • Product

• Brand: Futronic

• Model Number: FS88H

• Warranty: 1 year

• Origin: Hong Kong

• Manufactured by: Futronic Technology Co. Ltd.

• • OS Support & System Requirements

  • OS Support: Windows XP/2003, Vista/2008/2012, 7/8, Linux (kernel 2.4 or higher), macOS (10.5 to 10.7), Android (3.1 and higher with USB Host)

  • Memory: 16K Byte memory

• • Images & Capture

• Sensor Type: CMOS optical sensor

• Resolution: 320 x 480 pixels, 500 DPI

• Grayscale: 8-bit grayscale

• Image Size: 16.26 x 24.38 mm

• Supported Image File: 150K byte

• FBI / Image Certifications: Certified by FBI for PIV compliance

• Speed/API Interface: USB 2.0, captures fingerprint images in 100 ms

• Image Quality Compliant: FIPS 201 and PIV-071006

• • Weight & Dimensions

• Product Weight: 150 grams

• Platen Size: 14 mm crown glass

• Sensing Area: 16.26 x 24.38 mm

• Scanner Assembly Dimensions: 66 x 66 x 29 mm

• • Power & Connectors

• Interface: USB 2.0

• Connector Type: USB

• Power Source: DC 4.5 to 5.5V via USB port

• • Conformance & Certifications

  • USB Certification: Yes

  • FCC/CE/UKCA Conformance: Yes

  • Air Discharge / Contact Discharge: ESD contact - 8KV, air discharge - 16KV

  • Equipment Safety: Complies with safety standards

• • Compliance/Certifications

• Regulatory Compliance: Mobile ID FAP20; Microsoft WHQL; FCC and CE, RoHS

• • Temperature & Humidity

• Operating Temperature: -10°C to 55°C

• Humidity: 0-90% non-condensing

• • Surface & Systems

  • Ingress Protection / Water / Dust: IP54 rating for the scanning window

  • Surface Durability: Durable crown glass surface

• • Compliance & Regulations

  • FCC: Yes

Features

1. High-Resolution Imaging: The device takes detailed fingerprint images that can be utilized for accurate recognition using state-of-the-art CMOS optical technology.

2. Live Finger Detection: Equipped with a special feature that detects live fingers and rejects fake ones made from silicone or play-doh; hence, perfect from a security viewpoint.

3. Robust Design: Made from 14 mm crown glass platen with scratch-resistant features that support long-term and heavy-duty use.

4. Fast Performance: Capture fingerprint images in just 100 milliseconds, thereby allowing fast and efficient processing.

5. Wide Compatibility: Quite compatible with various operating systems, notably, Windows, Linux, and macOS, hence versatile for different setups.

6. User-friendly software: It has compatible software that empowers users to manage fingerprint data easily and enables the use of live finger detection.

7. Traceability: Serial number embedding in each unit for easy tracing, a very important aspect of government and identity management projects.

Note: Before using the device, please check the app specifications to ensure compatibility. All government-based project apps support this device.
