mDESK8 IRIS & Fingerprint

Mantra mDESK8 IRIS & Finger Biometric Device is an innovative solution that combines biometric identification functionality in an Android tablet.

The mDESK8 is designed to develop in a robust sleek design to meet the rising demand for secure and fast identity verification solutions across industries. This device is best suited for use in government agencies, banks, hospitals, or anything that requires accurate identification.

mDESK8 is a STQC & PIV certified fingerprint and IRIS sensor for maximum accuracy and security. In terms of capacity, the device can support up to 3,000 fingerprint users and up to 3,000 card users. It can support up to 100,000 fingerprint templates/photos and an amazing transaction capacity of 100,000,000,000 items to ensure maximum usability and performance of mDESK8. The device has a 2.8-inch color touchscreen which serves as the main control unit of the device. It also provides access to various functions quickly, such as checking attendance that can be enabled or disabled depending on the function. QR code reading capability is integrated with a built-in 5MP parabolic autofocus camera and a 2MP fixed focus camera.

mDESK8 is powered by a Mediatek MT8735V/W Quad-core processor and comes with 2GB of RAM and 16GB of internal memory, expandable up to 64GB. This powerful connectivity ensures optimal system performance and space. It is enough to store biometric data using Android Marshmallow so that programmers can design unique applications based on their specific needs based on fingerprints. For security purposes, the mDESK8 comes with two IRIS scanners for proper identification using fingerprints and IRIS recognition. The device supports both 1:1 and 1: N recognition modes which makes it suitable for all forms of identification.

mDESK8 has a wide range of connectivity capabilities TCP-IP, WiFi (optional) and RS485 interfaces for integration into existing systems. It also has a USB interface for forward connection which accepts the FAT32 file system to share files efficiently and smoothly. This feature of the device allows printing via Bluetooth. The device acts as a ticket or equipment used in transactions

In terms of user convenience, mDESK8 has alarms for notifications and power management along with the possibility of sleep mode. The device also has body induction technology that turns on only when in use. Intuitive controls help users keep track of their behavior. Green and red LEDs show current operating status.

Mantra mDESK8 IRIS & Finger Biometric Device is an innovative multifunctional product that not only integrates biometric scanning technology, but also Android tablets, the company's combination of impressive stability and comprehensive functionality caters to a broad user base. Along with additional tools, this software is ideal for organizations that require accurate identity verification for attendance tracking, integration into school systems or as an identity and security system mDESK8 features as the best biometric devices. For more details and support of Mantra mDESK8, you can contact us at +918434384343 or Email: [email protected] . Whether you are a regular customer or a potential customer. With our full dedication to our customer and support services, we are always ready to help in getting the most out of your biometric solutions.

Specification

• Product

• Brand: Mantra

• Model Number: mDESK8

• Type: IRIS & Fingerprint Biometric Device

• Warranty : 1 Year

• Manufactured by : Mantra Softech India Pvt Ltd

• Processor

• Dynamic IP Allocation: Yes (optional M1 card or ID card)

• Processor Type: Mediatek MT8735V/W Quad Core (Cortex-A53)

• CPU Speed: 1.3 GHz

• Display

• Screen Size: 8 Inch Diagonal

• Display Resolution: 800 x 1280 pixels

• Display Type: Wide Viewing Angle Outdoor IPS Display with Capacitive Touch

• User Capacity

• User Registration Capacity: Up to 3,000

• Face Registration Capacity: Up to 1,000 faces

• User Record Management Capacity: 100,000 user records / 10,000 management records

• Memory

• RAM: 2 GB LPDDR3

• Storage: 16 GB Embedded Multi Media Card (eMMC)

• Expandable Storage: Micro SD Card Slot Supported, Expandable up to 64 GB

• Connectivity

• Wi-Fi: 802.11 a/b/g/n (2.4GHz Supported)

• GPS: Integrated GPS supports A-GPS, GLONASS, Geo Tagging

• Bluetooth: Bluetooth® 4.0 + LE Connectivity

• 4G/LTE Support: GSM 850/900/1800/1900, WCDMA B1&B8, LTE (Band 3 & 40)

• Cameras

• Front Camera: 2 MP Fixed Focus

• Rear Camera: 5 MP Auto Focus

• Algorithm and Matching Performance

• Power Management Functionality: Sleeping Function

• Matching Speed for Biometric Recognition: ≤1.0 second

• Algorithm Version for Face Recognition: Facev4.0

• Inbuilt Sensors

• Alarm Functionality: Yes

• Sensors: Ambient Light Sensor, Accelerometer, Gyroscope, Proximity Sensor

• Sound and Speaker

• Speaker: 1.2 W Internal Speaker

• Ports and Slots

• SIM Slot: Micro SIM Card Slot

• Micro SD Card Slot: Expandable up to 64 GB

• USB Ports: Micro USB 2.0 OTG, USB 2.0 Slave, Charging Port

• Headphone Jack: External 3.5mm Combo Headphone/Microphone Jack

• Power Supply and Battery

• Power Supply Requirement: 27W, 5V, 3A Charging AC Adapter

• Battery Capacity: 6000 mAh Li-ion Polymer, 22.8 Whr

• Dimensions and Weight

• Weight: Approx. 800 grams

• Dimensions (L x W x H): 286 x 156 x 44 mm

• Certifications and Compliance

• Certifications:

• STQC Certified Fingerprint Sensor

• STQC Certified IRIS Sensor

• IEC60950

• CE

• FCC

• RoHS

• External Device Support

• External Devices Supported: Bluetooth Printer & PINPAD (Optional)

Key Features

• 16 GB Flash for storage of Fingerprint templates / photos with transactions.

• 3G/4G/GPS/Bluetooth/ WiFi Connectivity

• 5MP AF and 2MP FF Camera for Aadhaar QR Code Reading

• Fingerprint Sensor & IRIS Sensor with UDAI/STQC approvals

• Quad core processor technology & Android operating system

• Power On / Off Button, Volume Control Button, SIM & SD Card Terminal, USB 2.0

Note: Before using the device, please check the app specifications to ensure compatibility. All government-based project apps support this device.
