Tatvik 20 Single Fingerprint USB Scanner - TMF 20

The Tatvik 20 Single Fingerprint USB Scanner—TMF 20—is a high-performance FAP20 optical fingerprint scanner designed for versatile biometric authentication and individual identity verification.

Encased in a strong and compact housing, the TMF20 is lightweight and easily portable, thus offering great possibilities in various applications such as Aadhaar authentication, attendance tracking, Time & Attendance Tracking, Access Control, Individual Verification, and payment processing.

The TMF20 is compatible with Windows, Linux, and Android operating systems; hence, it can be easily integrated into any new or existing applications. This scanner uses USB 2.0/3.0 for a reliable power supply while ensuring easy connectivity.

The Tatvik TMF20 Single Fingerprint Scanner is also an STQC-certified registered device under UIDAI standards and hence Level 0 compliant. It finds a place in many sectors, from banking to health and government services.

You can purchase the Tatvik TMF20 at the best price in India through the Radium Box website. The Tatvik TMF20 Driver download is free for individuals who need the software to quickly install and configure it.  If you have queries regarding the Tatvik Fingerprint Scanner device, need assistance with Tatvik RD Service, or require support for the Tatvik biometric device driver download, feel free to contact our customer service at +91 84343 84343 or email us at: [email protected]. For the latest updates on Tatvik TMF20 recharge and Tatvik RD service APK download, visit the Radium Box official website.

Specification

• Products

  • Brand: Tatvik

  • Model Number: TMF20

  • Security Level: L0

  • Warranty: 1 Year

  • RD Service: Available

  • Origin: India

  • Manufactured by: Tatvik Biosystems Pvt Ltd.

• OS Support & System Requirements

  • OS Support: Windows 7/ 8/10, Linux, Android

• Images & Capture

  • Sensor Type: Optical fingerprint sensor

  • Resolution: 500 Dpi

  • Grayscale: 8-bit, 256 levels

  • FBI / Image Certifications: FBI-PIV Certified

  • Speed/API Interface: High-speed USB connectivity

  • Quality Scoring: High-quality fingerprint images

• Weight & Dimensions

  • Product Weight: 60 grams

  • Platen Size: 15.24 x 20.32 mm

  • Scanner Assembly Dimensions: 58 x 38 x 27 mm

• Power & Connectors

  • Interface: USB 2.0/3.0

  • Connector Type: USB

  • Power Source: USB powered

  • USB Voltage Level: 5V

• Conformance & Certifications

  • USB Certification: Yes

  • FCC/CE/UKCA Conformance: FCC, CE, RoHS compliant

• Compliance/Certifications

  • Fingerprint Capacity: 100000

  • Identification Speed: <3 Sec

• Temperature & Humidity

  • Operating Temperature: 0°C to 55°C

  • Humidity: 10-90%, non-condensing

  • Storage Temperature: -10°C to 60°C

• Surface & Systems

  • Ingress Protection/ Dust: IP54 rated

  • Surface Durability: Durable and lightweight design

  • Waterproof: No

• Compliance & Regulations

  • FCC: Yes

Features:

• Lightweight and durable to make it mobile for use anywhere.

• Provides high-resolution fingerprint images to capture biometric data with high accuracy.

• Compliant with FAP20 Large active platen area size to enhance fingerprint capture.

• Inbuilt FMR Extractor and Matcher, It houses advanced algorithms for efficient fingerprint matching and extraction.

• Security in data transfer between the scanner and devices connected to it.

• This adds an extra layer of security by providing RSA signature verification, which verifies the integrity of the device while booting.

• Trusted within a secure environment lies the Finger capture and Extraction Module, thus securing sensitive data.

• This hardware RSA keystore powers secure signing and encryption with RSA-2048, AES-256, SHA-256, and True Random Number Generation.

• Live Finger Detection, It utilizes AI-based applications in the detection of live fingers, thus enhancing security during authentication.

Note: Before using the device, please check the app specifications to ensure compatibility. All government-based project apps support this device.
